Electronic Wet Chemical Ultra-Pure Drums

ICAS™

IC55UP

C55UP

Over two plus decades, COEXCELL is recognized as the preeminent innovator in producing uniquely engineered, multi-layer HDPE plastic molded drums. With the introduction of our proprietary ICAS(Integrated Clean Air System) technology we have taken our processes and the purity of our IC55 and C55 drums to a whole new level.

IC55UP – AN EXCEPTIONAL DRUM WITH SUPERIOR CHARACTERISTICS

  • IC55UP flange openings accept industry standard high purity extraction, gasket and O-ring styles used in ultra clean applications.
  • IC55UP drums are certified for ultra clean integrity in COEXCELL’s Class 100 liquid particle count test laboratory. Here we can provide purity certification to the highest industry level.
  • Three layer drum configuration isolates color concentrates and UV stabilizers in the outside layers of the IC55UP drums.
  • Virgin inner liner layer made with proprietary ultra clean resin assures chemical contact with the purest HDPE available..
  • UN/DOT tested and certified for transport of Group II and Group III chemistry with and without dip-tube.
  • Patented drum design with integral sump below the flange for maximum extraction capability.]
  •  One piece design delivers molded in handling capabilities
  • Integral chime withstands heavier chemicals with a high specific gravity and elevated temperatures
IMG_0037



IC55UP – Available in 300 kPa

  • kPa is a unit of pressure measurement used to quantify internal pressure or stress.
  • Coexcell drums at the time of manufacture  – are tested for kPa to satisfy UNDOT requirements.
  • Coexcell offers drums with a 150kPa rating up to and including 300kPa.
  • Coexcell is proud to offer a UNDOT rated drum embossed with a 1H1/Y1.9/300 rating in a 55 gallon drum for high pressure rated chemistries..  .
  • 300kPa drums are made to handle higher pressure chemistries, such as Ammonium Hydroxide and aggressive Hydrofluoric Acid (HF) blends.
  • The 300kPA drum rating allows for global shipment of high pressure chemistries.
IMG_0104

IC55UP SPECIFICATIONS

Top Diameter

23.32” (59.23 cm)

Overall Height

35.9” (91.19 cm)

Overflow Capacity

59 gal. (223.3 liters)

Drum Body Weight

23.4 lbs. (10.6 kg)

View Our Literature

Thinking Inside The Drum

IC55, C55, and K55 Spec Sheet
